PT100 250Ω PRO T31 Temperature Electrical Transducer 35mm Rail

PT100 250Ω PRO T31 Temperature Electrical Transducer 35mm Rail

1. Product Description

Pro Series Transducers for Electrical Quantities, fundamental devices for process automation. All our

 instruments fulfill all important requirements and regulations concerning electromagnetic compatibility

and safe isolation (IEC688-1992 standard and GB/T 13850-1998 standard). The devices have been

developed, manufactured and tested in accordance with Quality Assurance System ISO 9001.

2. Technical Specification

Accuracy: Class0.2, 0.5

Auxiliary Power Supply: 85V~265VDC/AC 24V~80VDC/AC

Stability: Annual Change Rate ≤±0.2%

Input Overload Capacity:

Continuous Overload Capacity ≤1.5X

Transient Overload Capacity  Voltage Limit≤3X  Current Limit≤30X

Output:

Constant Voltage Output, Load Resistor    Rext≥250Ω

Constant Current Output, Load Resistor    Rext≤500Ω

Alternating Wave: ≤18mV(Peak-Peak)

Response Time: ≤300ms

Striking Voltage: ≤2.5kV

Operating Temperature: -10℃~+55℃

Storage Temperature: -40℃~+85℃

Relative Humidity of Annual Mean: ≤90%RH

Installation: DIN 35mm Rail

Size: 35mm×69mm×110mm

Guaranty Period: 2 years

3. Technical Data

Input: Cu50/PT50/Cu100/PT100

Output: 4~20mA, 0~20mA, 0~1mA, 0~10mA, 0~5V, 0~10V.

4. Wiring

   PRO T31 Wiring Diagram
