AC Voltage Electrical Transducer


Large Image :  AC Voltage Electrical Transducer Get Best Price

Product Details:
Place of Origin: China
Brand Name: Artel
Model Number: U31/32/33 AC
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Wooden box
Delivery Time: 1 month
Payment Terms: TT
Detailed Product Description
COM: Common Terminal COM: Common Terminal
UH: Auxiliary Power Supply Installation: DIN 35mm Rail
High Light:

frequency transducer


voltage transducer

AC Voltage Electrical Transducer , GB/T 13850-1998



1. Product Description


Pro Series Transducers for Electrical Quantities, fundamental devices for process automation. All our instruments fulfill all important requirements and regulations concerning electromagnetic compatibility and safe isolation (IEC688-1992 standard and GB/T 13850-1998 standard). The devices have been developed, manufactured and tested in accordance with Quality Assurance System ISO 9001.



2. Technical Specification


Accuracy: Class0.2, 0.5

Auxiliary Power Supply: 85V~265VDC/AC 24V~80VDC/AC

Stability: Annual Change Rate ≤±0.2%

Input Overload Capacity:

Continuous Overload Capacity ≤1.5 X

Transient Overload Capacity  Voltage Limit≤3X  Current Limit≤30X


Constant Voltage Output, Load Resistor    Rext≥250Ω

Constant Current Output, Load Resistor    Rext≤500Ω

Alternating Wave: ≤18mV(Peak-Peak)

Response Time: ≤300ms

Striking Voltage: ≤2.5kV

Operating Temperature: -10℃~+55℃

Storage Temperature: -40℃~+85℃

Relative Humidity of Annual Mean: ≤90%RH

Installation: DIN 35mm Rail

Size: 35mm×69mm×110mm

Guaranty Period: 2 years



3. Technical Data


Input: 0~100V/0~120V/0~220V/0~380V/0~500V/0~600V

Output: 4~20mA, 4~20mA(2-wire),0~20mA,0~10mA,0~1mA,0~5V,0~10V,0-1V



4. Wiring


 AC Voltage Electrical Transducer 0PRO U31 Wiring Diagram


“OUT”  Output In Correspondence

“IN”    Input Current  Variables

“UH”    Auxiliary Power Supply


Note: 2-wire transducer just can select 24VDC auxiliary power supply and 4-20mA output signal.

AC Voltage Electrical Transducer 1

               PRO U32 2in1 Wiring Diagram


UA, UC :   Input Voltage Variables

UH:            Auxiliary Power Supply

OA+, OC+:    Anode of Output In Correspondence to UA, UC

OA-, OC-:   Cathode of Output In Correspondence to UA, UC

AC Voltage Electrical Transducer 2


                   PRO U33 3in1 Wiring Diagram


UA, UB, UC:   Input Voltage Variables

UH:          Auxiliary Power Supply

OA, OB, OC:  Output In Correspondence to UA, UB, UC

COM:        Common Terminal
